SMCJ36 Dc Components
Same model may have multiple batches, images only for reference.

SMCJ36

Part No SMCJ36
Manufacturer Taiwan Semiconductor
Catalog TVS - Diodes
Description 1500W, 44.5V, 10%, UNIDIRECTIONA / 64.3V Clamp 24A Ipp Tvs Diode Surface Mount DO-214AB (SMC)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Taiwan Semiconductor
Series SMCJ
Package Tape & Reel
Product Status Active
Type Zener
Unidirectional Channels 1
Voltage - Reverse Standoff (Typ) 36V
Voltage - Breakdown (Min) 40V
Voltage - Clamping (Max) @ Ipp 64.3V
Current - Peak Pulse (10/1000µs) 24A
Power - Peak Pulse 1500W (1.5kW)
Power Line Protection No
Applications General Purpose
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Surface Mount
Package / Case DO-214AB, SMC
Supplier Device Package DO-214AB (SMC)
Base Product Number SMCJ36
Standard Package 3,000 pcs
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 668926-SMCJ36
Ultra Librarian 3D Model Ultra Librarian SMCJ36 CAD Model

Description

The 668926-SMCJ36 is a unidirectional Zener TVS diode designed for general-purpose circuit protection. It has a reverse standoff voltage of 36V and a breakdown voltage of 40V, providing reliable protection against transient voltage spikes.

  • Type: Unidirectional Zener TVS diode
  • Application: General-purpose circuit protection
  • Reverse Standoff Voltage: 36V
  • Breakdown Voltage: 40V
  • Clamping Voltage @ Peak Pulse Current: 64.3V
  • Peak Pulse Power Rating: 1500W
  • Current Rating for Peak Pulse Duration: 24A for 10/1000μs
  • Package Type: DO-214AB, SMC
  • Standard Package: 3,000 pieces
  • Manufacturer: Taiwan Semiconductor
  • Market Status: Active
