Same model may have multiple batches, images only for reference.

BZD27C24P

Name: BZD27C24P
Brand: Taiwan Semiconductor
SKU: 574289
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	BZD27C24P
Manufacturer	Taiwan Semiconductor
Catalog	Diodes - Zener - Single
Description	SUB SMA, 1000MW, 6%, ZENER DIODE
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Discrete Semiconductor Products - Diodes - Zener - Single Zener Diodes
Mfr	Taiwan Semiconductor
Package	Tape & Reel
Product Status	Active
Voltage - Zener (Nom) (Vz)	24.2 V
Tolerance	±5.79%
Power - Max	1 W
Impedance (Max) (Zzt)	15 Ohms
Current - Reverse Leakage @ Vr	1 µA @ 18 V
Voltage - Forward (Vf) (Max) @ If	1.2 V @ 200 mA
Temperature Range - Operating	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Package / Case	SOD-123
Supplier Device Package	Sub SMA
Base Product Number	BZD27
Standard Package	10,000 pcs
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8541.10.0050
Win Source Part Number	574289-BZD27C24P
Ultra Librarian 3D Model	Ultra Librarian BZD27C24P CAD Model

Alternative Products

Description

The 574289-BZD27C24P is a single Zener diode in a surface mount SOD-123 package.

Maximum Power Rating: 1 W
Forward Voltage: 1.2 V @ 200 mA
Reverse Leakage Current: 1 µA @ 18 V
Zener Voltage: 24.2 V
Tolerance: ±5.79%
Maximum Impedance: 15 Ohms
Applications: voltage regulation and protection against voltage spikes
Operating Temperature Range: -55°C to 175°C
Manufacturer: Taiwan Semiconductor
Package: tape and reel package of 10,000 pcs
