BAT54W RVG Taiwan Semiconductor
Same model may have multiple batches, images only for reference.

BAT54W RVG

Part No BAT54W RVG
Manufacturer Taiwan Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 30V 200MA SOT323
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr Taiwan Semiconductor
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 30 V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 1 V @ 100 mA
Speed Small Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr) 5 ns
Current - Reverse Leakage @ Vr 2 µA @ 25 V
Capacitance @ Vr, F 10pF @ 1V, 1MHz
Mounting Type Surface Mount
Package / Case SC-70, SOT-323
Supplier Device Package SOT-323
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number BAT54
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 436857-BAT54W RVG
Ultra Librarian 3D Model Ultra Librarian BAT54W RVG CAD Model

Description

The 436857-BAT54W RVG is a single diode in the SC-70, SOT-323 package.

  • Series: BAT54 series from Taiwan Semiconductor
  • Package: SC-70, SOT-323
  • Type: Schottky diode
  • Maximum Reverse Voltage: 30 V
  • Average Rectified Current Rating: 200 mA
  • Forward Voltage: 1 V @ 100 mA current
  • Reverse Recovery Time: 5 ns
  • Reverse Leakage Current @ 25 V: 2 μA
  • Capacitance @ 1 V and 1 MHz frequency: 10 pF
  • Operating Temperature Range: -55°C to 150°C
  • Mounting Type: Surface mount
  • Standard Package: 3,000 pieces
