The VN920B5HTR-E is a cutting-edge high-side driver manufactured by STMicroelectronics, designed for automotive and industrial applications. This device is part of the VIPower M0-5 family and is engineered to handle high current loads with great efficiency and reliability.

Key Features

• High-Side Switch: The VN920B5HTR-E acts as a high-side switch, enabling power to be applied to loads that are grounded permanently. This is particularly useful in automotive environments where loads are often connected directly to the chassis ground.
• Current Rating: It can sustain a continuous current of up to 12 A, making it suitable for driving a wide range of high-power devices.
• Integrated Protections: The device includes several protection features such as overtemperature shutdown, load current limitation, and active clamp to enhance system reliability and safety.
• Diagnostic Functions: Built-in diagnostic capabilities allow for the detection of open load in off-state, loss of ground and supply, and thermal shutdown status, enabling sophisticated control and monitoring of the load status.
• Voltage Range: The VN920B5HTR-E operates over a wide voltage range from 5.5V to 36V, accommodating various application requirements and ensuring compatibility with automotive battery voltage fluctuations.

Applications

The VN920B5HTR-E is primarily used in the automotive industry for controlling and driving various loads such as lights, heaters, motors, and solenoids. However, its robust design also makes it suitable for industrial applications where high-side power switching is required.

Package and Quality

This device is available in a small and thermally efficient SO-8 package, which minimizes PCB space requirements while maximizing thermal dissipation. The VN920B5HTR-E meets the stringent quality standards required in automotive applications, including compliance with the AEC-Q100 qualification.

Conclusion

With its robust design, comprehensive protection features, and diagnostic capabilities, the VN920B5HTR-E from STMicroelectronics represents a reliable and efficient solution for high-side driving applications in both the automotive and industrial sectors.
