TSV914IPT Precision Op-Amp by STMicroelectronics

The TSV914IPT is a state-of-the-art operational amplifier (op-amp) from STMicroelectronics, designed to meet the rigorous demands of precision analog applications. This high-performance device is part of the TSV91x series, which is renowned for its low-power consumption and excellent accuracy.

One of the standout features of the TSV914IPT is its rail-to-rail input and output capability, which allows for a wide dynamic range and makes it ideal for single-supply operations as well as dual supplies ranging from 2.5V to 5.5V. This flexibility makes it suitable for a broad array of applications, including battery-powered devices, portable instrumentation, and medical equipment.

With a gain bandwidth product of 4 MHz and a slew rate of 1.3 V/µs, this op-amp provides a good balance between speed and power consumption, with a quiescent current of just 850 µA at 5V. This combination of features ensures that the TSV914IPT can efficiently handle a wide range of signals without compromising on power efficiency, making it an excellent choice for energy-sensitive designs.

Key Features:

• Rail-to-rail input and output
• Low-power consumption: 850 µA at 5V
• Wide bandwidth: 4 MHz gain bandwidth product
• High slew rate: 1.3 V/µs
• Low input offset voltage: 900 µV max
• Operating voltage range: 2.5V to 5.5V
• Extended temperature range: -40°C to +125°C
• ESD tolerance: 4 kV HBM / 200 V MM

The TSV914IPT also boasts excellent ESD protection, with a human body model (HBM) rating of 4 kV and a machine model (MM) rating of 200 V, ensuring robustness and reliability in the field. Its extended temperature range from -40°C to +125°C guarantees performance in a wide range of environmental conditions.

STMicroelectronics has packaged the TSV914IPT in a compact TSSOP-14 package, optimizing the board space and making it a convenient choice for space-constrained applications. Whether you're designing for consumer electronics, automotive systems, or industrial controls, the TSV914IPT op-amp is engineered to deliver precision, efficiency, and reliability.
