The STM32F105VCT6 is a high-performance ARM Cortex-M3 based microcontroller from STMicroelectronics. This advanced MCU is part of the STM32F1 Connectivity line, designed to offer a perfect blend of access speed, performance, and cost-effectiveness. It is particularly suitable for industrial, medical, and consumer applications that require a high level of integration and connectivity options.

Key Features

• Core: ARM Cortex-M3 32-bit RISC core operating at a 72 MHz frequency.
• Memory: 256 KB of Flash memory and 64 KB of SRAM, providing ample space for complex applications.
• I/Os: Up to 80 fast I/O ports, all mappable on 16 external interrupt vectors and almost all 5V-tolerant.
• Debugging: Serial wire debug (SWD) and JTAG interfaces for full-speed system development.
• Connectivity: Includes USB 2.0 full-speed device/host/OTG controller with on-chip PHY, CAN, two I2C interfaces, three USARTs, two SPIs, and an SDIO interface.
• Timers: Three 16-bit timers, one PWM timer for motor control, and two 16-bit watchdog timers.
• Analog: Two 12-bit analog-to-digital converters, providing up to 1 MSPS, up to 16 channels.
• Power Efficiency: 2.0 to 3.6 V application supply and I/Os, POR, PDR, and programmable voltage detector (PVD).
• Package: Available in a 100-pin LQFP package.

Applications

The versatility of the STM32F105VCT6 makes it ideal for a wide range of applications, including:

• Industrial control systems
• Medical equipment
• Embedded systems
• Point-of-sale terminals
• Networking systems
• Robotics

Development Support

STMicroelectronics provides comprehensive development support for the STM32F105VCT6 with software libraries, development kits, and the STM32Cube ecosystem. This extensive support simplifies the development process, from initial prototyping to final product production, ensuring a seamless and efficient design experience.
