STMicroelectronics ST72F324BK2T6 Microcontroller

The ST72F324BK2T6 is a robust 8-bit microcontroller from STMicroelectronics, designed to offer an optimal blend of performance, efficiency, and versatility for a wide range of embedded applications. This microcontroller is part of the ST7 family, which is known for its high reliability and advanced features tailored to meet the demands of industrial, automotive, and consumer markets.

Key Features

• Core: The ST72F324BK2T6 is built around a high-performance 8-bit CPU core, operating at a maximum frequency of 8 MHz, which provides the computational power necessary for complex tasks and real-time processing.
• Memory: It comes equipped with 16 KB of Flash program memory, ensuring ample space for application code, and 1 KB of RAM for data storage, facilitating efficient operation.
• I/O Ports: The device features 28/32 programmable I/O lines, allowing for flexible interfacing with peripherals and external devices, making it suitable for a variety of control applications.
• Advanced Peripherals: It includes a range of integrated peripherals such as an 8-channel, 10-bit A/D converter, a 2-channel, 16-bit timer, a main oscillator, and a watchdog timer, enhancing its functionality and reducing the need for external components.
• Communication Interfaces: The microcontroller supports SPI and I2C communication protocols, enabling easy connectivity with other microcontrollers, sensors, and modules.
• Operating Voltage: It operates within a voltage range of 3.0 to 5.5 V, making it versatile for use in both 3.3V and 5V systems.
• Temperature Range: The ST72F324BK2T6 is designed to perform reliably in extreme conditions, with an operating temperature range of -40°C to +85°C.
• Packaging: Available in a 32-pin LQFP package, it offers a compact footprint suitable for space-constrained applications.

Applications

The microcontroller's feature set makes it an excellent choice for applications such as automotive systems, industrial control units, home appliances, and consumer electronics. Its robust design and comprehensive set of peripherals enable developers to create efficient and reliable embedded systems with reduced development time and cost.

With the ST72F324BK2T6, STMicroelectronics continues to deliver high-quality, high-performance microcontrollers that empower designers to bring their innovative ideas to life in a myriad of embedded applications.
