ST1480ACDR Transceiver by STMicroelectronics

The ST1480ACDR is a state-of-the-art transceiver module designed and manufactured by STMicroelectronics, a leader in the semiconductor industry. This product is a part of the low-power, high-speed transceiver family that is capable of operating on a single 3.3V supply. It is specifically tailored for balanced transmission lines and complies with the RS-485 and RS-422 standards for serial communication.

Key Features

• High Data Transfer Rates: The ST1480ACDR supports data rates up to 10 Mbps, making it suitable for high-speed communication in industrial, networking, and telecommunication applications.
• Low Power Consumption: Designed with energy efficiency in mind, it operates on a low supply current, which is ideal for power-sensitive designs.
• Extended Common-Mode Range: The ±12 V range enhances the device's robustness against common-mode noise and allows for reliable data transmission in electrically noisy environments.
• Thermal Shutdown Protection: The built-in thermal shutdown feature ensures that the device is protected from damage due to excessive power dissipation.
• Driver Differential Outputs: The transceiver features an open-circuit, short-circuit, and idle-bus fail-safe receiver inputs, which contribute to the integrity of the communication link.

Applications

• Industrial Control Systems
• Building Automation
• Networked Security Systems
• Point of Sale (PoS) Terminals
• Data Communication Systems

The ST1480ACDR is encapsulated in an 8-pin SOIC package, which is compact and suitable for space-constrained applications. The combination of its robust design and high-speed capabilities makes it an excellent choice for implementing balanced transmission lines in a wide array of electronic systems.

STMicroelectronics' commitment to quality ensures that the ST1480ACDR transceiver delivers reliable performance and meets the stringent requirements of modern electronic communication protocols. With its advanced features and versatile applications, the ST1480ACDR is a top-tier component for designers looking to enhance the efficiency and reliability of their digital communication solutions.
