STMicroelectronics M24C16-RDW6TP EEPROM

The M24C16-RDW6TP is a high-performance 16-Kbit serial EEPROM from STMicroelectronics, designed for a wide range of applications that require reliable and efficient non-volatile memory storage. This compact EEPROM device is part of the M24C series, which is well-known for its robustness and endurance, making it an ideal choice for advanced data storage solutions.

Featuring a flexible I²C interface, the M24C16-RDW6TP allows for easy integration into various electronic systems, with a supply voltage range of 2.5V to 5.5V. This makes it compatible with both 3.3V and 5V logic levels, providing designers with the versatility to use it in multiple environments without the need for level shifters or additional power supplies.

The M24C16-RDW6TP offers a storage capacity of 16 Kbits, organized as 2K x 8 bits, which is sufficient for storing configuration parameters, calibration data, or small application logs. The memory array is optimized for low power consumption and high-speed data transfer, with a maximum clock frequency of 400 kHz in the Fast-mode I²C protocol.

One of the key features of this EEPROM is its byte and page write capability, which allows for efficient data management and minimizes write cycles. The page write buffer size is 16 bytes, enabling quick updates of data blocks. Additionally, the device supports both random and sequential read modes, providing flexible and fast data retrieval options.

The M24C16-RDW6TP is designed with data protection in mind. It includes a write control feature through a Write Protect (WP) pin, which ensures that data cannot be altered accidentally. Additionally, the device is equipped with an automatic write cycle completion with an internal timing generator, which further enhances data integrity by ensuring that each write operation is fully completed before the next one begins.

STMicroelectronics has packaged the M24C16-RDW6TP in a small TSSOP8 package, which is suitable for space-constrained applications. The device is also compliant with the RoHS directive, making it environmentally friendly and suitable for use in a wide range of consumer and industrial products that demand high-quality, reliable memory storage solutions.
