GBU401G SMC Diode Solutions
Same model may have multiple batches, images only for reference.

GBU401G

Part No GBU401G
Manufacturer SMC Diode Solutions
Catalog Bridge Rectifiers
Description BRIDGE RECT 1PHASE 100V 4A GBU
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr SMC Diode Solutions
Series -
Package Tube
Product Status Active
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 100 V
Current - Average Rectified (Io) 4 A
Voltage - Forward (Vf) (Max) @ If 1.1 V @ 4 A
Current - Reverse Leakage @ Vr 5 µA @ 100 V
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case 4-ESIP
Supplier Device Package GBU
Base Product Number GBU401
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 1368014-GBU401G
Ultra Librarian 3D Model Ultra Librarian GBU401G CAD Model

Description

The GBU401G is a bridge rectifier diode from SMC Diode Solutions.

  • Mounting Type: Through-Hole
  • Package: 4-ESIP
  • Product Status: Active
  • Maximum Average Rectified Current: 4A
  • Maximum Forward Voltage: 1.1V @ 4A
  • Voltage Rating: 100V
  • Temperature Range: -55°C to 150°C
  • Recovery Type: Standard Recovery
  • Recovery Time: Fast, less than 500ns
