BAT43W Real Image BAT43W real image17569 BAT43W Real Image1 BAT43W Real Image2
Same model may have multiple batches, images only for reference.
BAT43W Real Image BAT43W real image17569 BAT43W Real Image1 BAT43W Real Image2
BAT43W Real Image BAT43W real image17569 BAT43W Real Image1 BAT43W Real Image2
Same model may have multiple batches, images only for reference.

BAT43W

Part No BAT43W
Manufacturer SMC Diode Solutions
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 30V 200MA SOD123 / Diode 30 V 200mA Surface Mount SOD-123
Datasheet
BAT43W Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr SMC Diode Solutions
Package Tape & Reel
Product Status Active
Technology Schottky
Voltage - DC Reverse (Vr) (Max) 30 V
Current - Average Rectified (Io) 200mA
Voltage - Forward (Vf) (Max) @ If 1 V @ 200 mA
Speed Small Signal =< 200mA (Io), Any Speed
Current - Reverse Leakage @ Vr 500 nA @ 25 V
Capacitance @ Vr, F 10pF @ 1V, 1MHz
Mounting Type Surface Mount
Package / Case SOD-123
Supplier Device Package SOD-123
Operating Temperature - Junction -55°C ~ 150°C
Base Product Number BAT43
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 568827-BAT43W
Ultra Librarian 3D Model Ultra Librarian BAT43W CAD Model

Description

The BAT43W is a Schottky diode with a maximum DC reverse voltage of 30V and an average rectified current of 200mA.

  • Forward Voltage: 1V @ 200mA
  • Reverse Leakage Current: 500nA @ 25V
  • Capacitance: 10pF @ 1V and 1MHz
  • Operating Temperature Range: -55°C to 150°C
  • Mounting: suitable for surface mount applications
  • Package: SOD-123 package
  • Standard Package: 3,000 pcs
  • Status: active product
  • Manufacturer: SMC Diode Solutions
  • Commonly used in: various electronic circuits
