SMS7630-006LF Skyworks Solutions Inc. SMS7630-006LF Real Image
Same model may have multiple batches, images only for reference.
SMS7630-006LF Skyworks Solutions Inc. SMS7630-006LF Real Image
SMS7630-006LF Skyworks Solutions Inc. SMS7630-006LF Real Image
Same model may have multiple batches, images only for reference.

SMS7630-006LF

Part No SMS7630-006LF
Manufacturer Skyworks Solutions Inc.
Catalog RF Diodes
Description DIODE SCHOTTKY MIXER 1V SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Skyworks Solutions Inc.
Packaging Reel - TR
Status Active
Diode Type Schottky - 1 Pair Series Connection
Voltage - Peak Reverse (Max) 1V
Current - Max 50mA
Power Dissipation (Max) 75mW
Temperature Range - Operating 150°C (TJ)
Case / Package SOT-23-3
Win Source Part Number 125964-SMS7630-006LF
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SMS7630-006LF CAD Model

Description

The Skyworks Solutions Inc. SMS7630-006LF is a Schottky diode with a current rating of 50mA.

  • Manufacturer: Skyworks Solutions Inc.
  • Product Name: SMS7630-006LF
  • Current Rating: 50mA
  • Voltage-Peak Reverse: 1V
  • Power Dissipation: 75mW
  • Category: Discrete Semiconductor Products
  • Status: Active
  • Operating Temperature Range: 150°C (TJ)
  • Package/Case: SOT-23-3
  • Supply and Demand Status: Balanced
