The SiTime SIT8102AC-23-33S-24.00000T is a programmable oscillator from SiTime's SiT8102 series, which are known for their high performance, small size, and excellent reliability. The part number breaks down as follows: 'AC' likely refers to specific operating voltage and temperature characteristics, '23' suggests certain configuration options or performance characteristics, '33S' implies certain supply voltage and stability parameters, and '24.00000T' specifies the output frequency of 24 MHz. This oscillator is designed to provide a stable and precise clock signal for various electronic applications.

Applications

• Consumer electronics
• Industrial control systems
• Networking equipment
• Microcontrollers
• FPGA clocking

Features

• Frequency: 24 MHz
• Supply Voltage: 3.3V
• Excellent frequency stability
• Wide temperature range
• Small footprint
• Low power consumption
• Pb-free and RoHS compliant
• Programmable features

Benefits

• Provides a highly accurate and stable clock signal, improving system performance.
• Enables compact designs due to its small size.
• Offers flexibility through programmability, allowing customization for specific application requirements.
• Reduces power consumption, contributing to energy efficiency.
• Ensures reliable operation in harsh environments due to its wide temperature range.

The SiT8102 series oscillators are based on MEMS (Micro-Electro-Mechanical Systems) technology, offering advantages over traditional quartz oscillators in terms of size, reliability, and robustness. This oscillator is commonly used in applications where precise timing is critical, such as data communication, signal processing, and embedded systems. Its low jitter and high stability ensure clean clock signals, minimizing errors and improving overall system accuracy.

Specifications:

• Frequency Stability: Typically ±20 ppm to ±50 ppm (depending on configuration)
• Operating Temperature Range: -40°C to +85°C
• Supply Voltage: 3.3V
• Output Signal: CMOS
• Package: typically 2.5 x 2.0 mm or smaller
