The SiTime SIT8002AI-43-33E-14.318 is a programmable oscillator from SiTime's SiT8002 series, renowned for its high performance, compact size, and excellent reliability. In the part number, 'AI' denotes a particular combination of operating voltage and temperature range, '43' may specify configuration options or performance characteristics, '33E' suggests supply voltage and stability parameters, and '14.318' signifies an output frequency of 14.318 MHz. This oscillator is engineered to provide a stable and precise clock signal, making it suitable for various electronic applications requiring this specific frequency.

Applications

• Communication Systems (e.g., UART, Serial Communication)
• Embedded Systems
• Microcontroller Clocking
• Audio Applications
• Industrial Control Systems

Features

• Frequency: 14.318 MHz
• Supply Voltage: 3.3V
• High frequency stability
• Small form factor
• Low power consumption
• Wide operating temperature range
• Programmable for customized applications

Benefits

• Provides a highly accurate and stable clock signal, improving system performance in timing-critical applications.
• Enables compact designs due to its small size.
• Offers flexibility through programmability, allowing for customization according to specific requirements.
• Reduces power consumption, contributing to energy efficiency.
• Ensures reliable operation in diverse environmental conditions due to its wide temperature range.

SiT8002 series oscillators use MEMS (Micro-Electro-Mechanical Systems) technology, providing advantages over traditional quartz oscillators in terms of size, robustness, and reliability. The 14.318 MHz frequency is commonly used in legacy communication interfaces. Its low jitter and high stability ensure clean clock signals, minimizing errors and improving overall system accuracy.

Specifications:

• Frequency Stability: Typically ±20 ppm to ±50 ppm (depending on configuration)
• Operating Temperature Range: -40°C to +85°C
• Supply Voltage: 3.3V
• Output Signal: CMOS
• Package: Typically 2.5 x 2.0 mm or smaller
