PFSM.100.2 Schurter Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

PFSM.100.2

Part No PFSM.100.2
Manufacturer Schurter Inc.
Catalog PTC Resettable Fuses
Description PTC RESET FUSE 30V 1.1A 2SMD
Datasheet
PFSM.100.2 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Polymeric
Voltage - Max 30V
Current - Hold (Ih) (Max) 1.1 A
Current - Trip (It) 2.2 A
Current - Max 80 A
Time to Trip 500 ms
Resistance - Initial (Ri) (Min) 120 mOhms
Resistance - Post Trip (R1) (Max) 480 mOhms
Temperature Range - Operating -40°C ~ 85°C
Grade Automotive
Qualification AEC-Q200
Mounting Type Surface Mount
Case / Package 2-SMD
Size / Dimension 0.289" L x 0.214" W (7.36mm x 5.44mm)
Thickness (Max) 0.118" (3.00mm)
Package Tape & Reel
Supply and Demand Status Limited
Win Source Part Number 1605389-PFSM.100.2
Ultra Librarian 3D Model Ultra Librarian PFSM.100.2 CAD Model
