The 2SD2060 is an NPN triple diffused type transistor manufactured by Savantic, Inc. This transistor is designed for high-power switching applications. It's commonly used in power supplies, motor control circuits, and other applications requiring high voltage and current handling capabilities.

Applications

• Power supplies
• Motor control circuits
• Inverters
• Switching regulators
• General-purpose switching

Features

• NPN Triple Diffused Type
• High breakdown voltage
• High current capability
• Low saturation voltage
• Fast switching speed

Benefits

• Efficient Power Switching: Enables efficient switching in power supplies and other high-power applications.
• Reliable Operation: Offers reliable performance due to its robust design and high breakdown voltage.
• Versatile Use: Can be used in a wide range of switching applications.
• Reduced Power Loss: Low saturation voltage minimizes power loss during switching.
• Improved System Performance: Fast switching speed contributes to improved system performance and efficiency.

Technical Specifications (Typical)

While specific datasheets from Savantic, Inc. are difficult to find, similar NPN high-power transistors usually feature the following characteristics:

• Collector-Emitter Voltage (VCEO): 400V - 600V (Estimated)
• Collector Current (IC): 5A - 10A (Estimated)
• Power Dissipation (PC): 50W - 80W (Estimated)
• Current Gain (hFE): Typically between 10 and 50 (at specified IC and VCE)
• Operating Temperature: -55°C to +150°C

Note: Always refer to the official datasheet for accurate and specific specifications before using this component in your design. As Savantic, Inc. datasheets can be hard to find, cross-referencing with similar transistors from other manufacturers is often necessary.
