The TSM-103-01-L-DV-M-TR is a through-hole header strip manufactured by Samtec Inc. These headers are designed for board-to-board connections and are commonly used in a wide range of electronic applications. They provide a reliable and cost-effective solution for connecting PCBs.

Applications:

• Board-to-Board Connections: Used to connect PCBs in electronic devices.
• Prototyping: Ideal for prototyping circuits and connecting components.
• Industrial Equipment: Used in industrial control systems and automation equipment.
• Medical Devices: Utilized in medical equipment for reliable board connections.
• Consumer Electronics: Found in various consumer electronic products for connecting different circuit boards.

Features:

• Through-Hole Mounting: Provides a secure and robust connection to the PCB.
• Dual Row: Increases the number of connections in a compact space.
• Gold-Plated Contacts: Ensures reliable electrical contact and corrosion resistance.
• Black Insulator: Made from high-temperature thermoplastic for durability.
• Tape and Reel Packaging: Suitable for automated assembly processes.

Benefits:

• Reliable Connection: Through-hole mounting and gold-plated contacts ensure a stable and reliable electrical connection.
• Increased Density: Dual-row design maximizes the number of connections in a limited space.
• Corrosion Resistance: Gold-plated contacts prevent corrosion, ensuring long-term reliability.
• Easy Assembly: Tape and reel packaging facilitates automated assembly processes.
• Versatile Application: Suitable for a wide range of electronic applications.

Additional Details:

The TSM series from Samtec are known for their high quality and reliability. Specifically, the TSM-103-01-L-DV-M-TR features 3 positions per row (resulting in a total of 6 pins), 01 indicates the series number, L designates a low-profile design, DV denotes dual-row vertical orientation, M indicates a matte finish and TR refers to tape and reel packaging. The contact material is typically a copper alloy with gold plating over nickel. These headers are designed to withstand high temperatures, making them suitable for reflow soldering processes. Always refer to the Samtec datasheet for detailed specifications, including current rating, voltage rating, and operating temperature range, to ensure proper application and performance. This is essential to ensure the header is used within its designed operational parameters. These headers are popular for their durability and ease of integration into various electronic designs.
