Name: SSW-150-02-S-D
Brand: Samtec Inc.
SKU: 1288920
Availability: InStock
Rating: 4.85 (5 reviews)

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	SSW
Package	Bulk
Connector Type	Receptacle
Contact Type	Forked
Style	Board to Board or Cable
Number of Positions	100
Number of Positions Loaded	All
Pitch - Mating	0.100" (2.54mm)
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	30.0µin (0.76µm)
Insulation Color	Black
Insulation Height	0.335" (8.51mm)
Contact Length - Post	0.194" (4.93mm)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Tin
Current Rating (Amps)	4.7A per Contact
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Phosphor Bronze
Base Product Number	SSW-150
Other Names	SAM1217-50,SAM1217-50,612-SSW-150-02-S-D
Standard Package	1
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1288920-SSW-150-02-S-D
Ultra Librarian 3D Model	Ultra Librarian SSW-150-02-S-D CAD Model

Description

The SSW series connector is a receptacle type connector with a forked contact type.

Positions: 100
Positions Loaded: All
Contact Material: Phosphor Bronze
Contact Finish - Mating: Gold
Contact Finish Thickness - Mating: 30.0µin (0.76µm)
Contact Finish - Post: Tin
Mounting Type: Through-Hole
Pitch-Mating: 0.100" (2.54mm)
Contact Shape: Square
Contact Length - Post: 0.194" (4.93mm)
Insulation Material: Liquid Crystal Polymer (LCP)
Insulation Height: 0.335" (8.51mm)
Temperature Range: -55°C ~ 125°C
Current Rating per Contact: 4.7A
ECCN: EAR99
Style: Board to Board or Cable
