The SSW-108-02-T-S is a receptacle connector from Samtec Inc. It is a rectangular connector with a pitch of 0.100" (2.54mm) and has 8 positions loaded in a single row.

• Pitch: 0.100" (2.54mm)
• Positions Loaded: 8
• Rows: 1
• Fastening Type: Push-Pull
• Termination: Soldering
• Insulation Material: Liquid Crystal Polymer (LCP)
• Flammability Rating: UL94 V-0
• Contact Material: Phosphor Bronze
• Contact Shape: Forked
• Contact Finish Mating: Tin
• Contact Finish Post: Tin
• Current Rating: 4.7A per contact
• Temperature Range: -55°C to 105°C
• Suitable for: Board-to-Board or Cable Style Connections
• Package: Bulk
• ECCN: EAR99
• REACH: Unaffected
