The Samtec Inc. SSQ series connector is a rectangular receptacle with a push-pull fastening type.

• Connector Type: receptacle
• Fastening Type: push-pull
• Positions: 58
• Contact Type: forked
• Positions Loaded: all
• Connection Style: board to board or cable
• Pitch Mating: 0.100 inches (2.54mm)
• Voltage Rating: 465VAC and 655VDC
• Temperature Range: -55°C to 125°C
• Insulation Material: liquid crystal polymer (LCP)
• Insulation Color: black
• Flammability Rating: UL94 V-0
• Mounting Type: through-hole
• Contact Material: phosphor bronze
• Contact Finish Mating: gold
• Contact Finish Post: gold
• Contact Finish Thickness (Post): 3.00µin (0.076µm)
• Row Spacing: 0.100 inches (2.54mm)
• Contact Length: 0.194 inches (4.93mm)
• Insulation Height: 0.335 inches (8.51mm)
• Contact Shape: square
• Ingress Protection: N/A
