The Tiger Eye™ SFMC series from Samtec Inc. is a receptacle connector with 90 positions, two rows, and a pitch of 0.050" (1.27mm).

• Connector Type: Receptacle
• Positions: 90
• Rows: Two
• Pitch: 0.050" (1.27mm)
• Contacts: Female socket contacts made from phosphor bronze
• Termination: Solder
• Current Rating: 2.9A per contact
• Applications: Board-to-board or cable applications
• Package: Tube
• Insulation Material: Liquid crystal polymer (LCP)
• Flammability Rating: UL94 V-0
• Contact Shape: Square
• Mounting: Through the hole
• Contact Finish (Mating): Gold with a thickness of 30.0µin (0.76µm)
• Contact Finish (Post): Tin
• Temperature Range: -55°C ~ 125°C
• ECCN: EAR99 compliant
• Suitable for: Use in various applications that require a high-density, low-profile connector.
