Name: SFM-125-01-S-D-A
Brand: Samtec Inc.
SKU: 1286988
Availability: InStock
Rating: 4.85 (5 reviews)

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	Tiger Eye™ SFM
Package	Tube
Connector Type	Receptacle
Contact Type	Female Socket
Style	Board to Board or Cable
Number of Positions	50
Number of Positions Loaded	All
Pitch - Mating	0.050" (1.27mm)
Number of Rows	2
Row Spacing - Mating	0.050" (1.27mm)
Mounting Type	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	30.0µin (0.76µm)
Insulation Color	Black
Insulation Height	0.180" (4.57mm)
Contact Length - Post	0.120" (3.05mm)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Tin
Mated Stacking Heights	6.02mm, 6.17mm, 7.80mm, 7.95mm, 9.58mm, 9.73mm, 11.48mm, 11.63mm
Features	Board Guide
Current Rating (Amps)	3.2A per Contact
Voltage Rating	250VAC
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Beryllium Copper
Base Product Number	SFM-125
Other Names	SAM11709,SFM-125-01-S-D-A
Standard Package	16
MSL Level	1 (Unlimited)
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1286988-SFM-125-01-S-D-A
Ultra Librarian 3D Model	Ultra Librarian SFM-125-01-S-D-A CAD Model

Description

The Tiger Eye™ SFM series female socket connector is a rectangular connector that is designed for board-to-board or cable-to-board applications.

Pitch: 0.050 inches (1.27mm)
Row Spacing: 0.050 inches (1.27mm)
Positions: 50
Rows: Two
Positions Loaded: All
Contact Type: Female socket
Contact Material: Beryllium copper
Termination Type: Solder
Fastening Type: Push-pull
Insulation Material: Liquid crystal polymer (LCP)
Insulation Height: 0.180 inches (4.57mm)
Contact Shape: Square
Contact Length: 0.120 inches (3.05mm)
Temperature Range: from -55°C to 125°C
Model: SFM-125-01-S-D-A
Package: Tube
Voltage Rating: 250VAC
