The Samtec Inc. SSA-125-W-T-RA is a rectangular connector with an SSA series.

• Number of Positions: 25
• Connector Type: Receptacle, Breakaway
• Contact Type: Female Socket
• Positions Loaded: All
• Number of Rows: 1
• Termination: Wire Wrap
• Fastening Type: Push-Pull
• Package: Bulk
• Contact Material: Phosphor Bronze
• Voltage Rating: 1000V
• Insulation Material: Polyethylene Terephthalate (PET), Polyester
• Flammability Rating: UL94 V-0
• Application: Board to Board
• Pitch-Mating: 0.100" (2.54mm)
• Finish-Mating: Tin
• Insulation Color: Black
• Mounting Type: Through Hole, Right Angle
• Insulation Height: 0.100" (2.54mm)
• Temperature Range: -55°C ~ 105°C
