The Samtec Inc. SS-128-T-2-N is a receptacle connector with 28 positions and a 0.100" (2.54mm) pitch mating.

• Positions: 28
• Pitch Mating: 0.100" (2.54mm)
• Row: Single
• Application: Board-to-board
• Contact Type: Female Socket
• Positions Loaded: All
• Termination: Solder
• Fastening Type: Push-Pull
• Contact Material: Beryllium Copper
• Contact Finish: Gold with a thickness of 30.0µin (0.76µm)
• Contact Finish (Post): Tin
• Insulation Material: Polybutylene Terephthalate (PBT), Glass Filled
• Insulation Color: Black
• Contact Shape: Circular
• Contact Length (Post): 0.125" (3.18mm)
• Insulation Height: 0.100" (2.54mm)
• Temperature Range: -55°C to 125°C
