The SEAM-30-03.5-S-06-2-A-K-TR is a high-speed edge card socket from Samtec Inc. This connector is designed for high-density and high-performance applications, providing a reliable connection between a PCB edge and a mating card. It features a fine pitch, a surface mount design, and gold-plated contacts for optimal signal integrity. The TR suffix indicates tape and reel packaging.

Applications

• PCIe Gen 4 and Gen 5 applications
• High-speed backplanes
• Graphics cards
• Networking equipment
• Storage devices

Features

• High-speed edge card socket
• Fine pitch design for high density
• Surface mount termination
• Gold-plated contacts for optimal signal integrity
• Tape and reel packaging for automated assembly

Benefits

• Enables high-speed data transfer
• Supports high-density designs
• Simplifies assembly processes
• Ensures reliable connections
• Reduces board space requirements

Additional Details

The SEAM-30-03.5-S-06-2-A-K-TR edge card socket is designed to meet the demanding requirements of high-speed applications. The fine pitch allows for increased density, reducing the overall size of the board. The surface mount termination simplifies assembly and improves reliability. The gold-plated contacts provide excellent conductivity and corrosion resistance, ensuring optimal signal integrity. The tape and reel packaging facilitates automated assembly processes.

This connector is part of Samtec's extensive line of high-performance interconnect solutions. It is designed to provide a reliable and cost-effective solution for a wide range of applications. The part number reveals many aspects of the connector such as the number of pins, row spacing and plating. The SEAM series is a high speed edge card system.
