SDL-112-T-11 Real Image
Same model may have multiple batches, images only for reference.

SDL-112-T-11

Part No SDL-112-T-11
Manufacturer Samtec Inc.
Catalog Rectangular Connectors
Datasheet
SDL-112-T-11 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Samtec Inc.
Series SDL
Package Tube
Connector Type Receptacle
Contact Type Female Socket
Style Board to Board
Number of Positions 24
Number of Positions Loaded All
Pitch - Mating 0.100" (2.54mm)
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Mounting Type Through Hole
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Insulation Color Black
Insulation Height 0.132" (3.35mm)
Contact Length - Post 0.108" (2.75mm)
Temperature Range - Operating -55°C ~ 125°C
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Circular
Contact Material Beryllium Copper
Base Product Number SDL-112
Other Names SAM1137-12
Standard Package 1
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1292894-SDL-112-T-11
Ultra Librarian 3D Model Ultra Librarian SDL-112-T-11 CAD Model

Description

The Samtec Inc. SDL-112-T-11 is a rectangular connector that belongs to the SDL series.

  • Manufacturer: Samtec Inc.
  • Product Name: SDL-112-T-11
  • Series: SDL
  • Type: rectangular connector
  • Style: receptacle
  • Rows: two
  • Positions: 24
  • Contacts: female sockets
  • Fastening Type: push-pull
  • Termination: solder
  • Contact Material: beryllium copper
  • Insulation Material: liquid crystal polymer (LCP)
  • Pitch: 0.100 inches (2.54mm)
  • Contact Finish: gold
  • Operating Temperature: -55°C to 125°C
  • Application: board-to-board connections
