Same model may have multiple batches, images only for reference.
QSH-060-01-F-D-A-K-TR Real Image
Same model may have multiple batches, images only for reference.

QSH-060-01-F-D-A-K-TR

Part No QSH-060-01-F-D-A-K-TR
Manufacturer Samtec Inc.
Catalog OEM Parts (O - R)
Description Board to Board & Mezzanine Connectors 0.50 mm Q Strip High-Speed Ground Plane Socket Strip
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Contact Material Bronze
Contact Plating Gold
Depth 7.49 mm
Gender Female
Housing Color Black
Housing Material Polymer
Lead Free Yes
Length 41.27 mm
Maximum Operating Temperature 125 °C
Max Voltage Rating (AC) 125 V
Min Operating Temperature -55 °C
Number of Contacts 120
Number of Rows 2
Orientation Straight
Packaging Tape and Reel
Pitch 500 µm
Radiation Hardening No
RoHS Compliant
Termination Solder
Voltage Rating (AC) 125 V
Win Source Part Number 1086953-QSH-060-01-F-D-A-K-TR
Categories OEM Parts(O-R)
Manufacturer Samtec Inc.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian QSH-060-01-F-D-A-K-TR CAD Model

Description

The Samtec Inc. QSH-060-01-F-D-A-K-TR is a 120-position female connector designed for board-to-board applications.

  • Positions: 120
  • Pitch: 500μm
  • Housing Material: Polymer
  • Contact Material: Bronze
  • Contact Plating: Gold
  • Voltage Rating: 125VAC
  • RoHS Compliant: Yes
