MTSW-120-22-T-D-380

Name: MTSW-120-22-T-D-380
Brand: Samtec Inc.
SKU: 812597
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	MTSW-120-22-T-D-380
Manufacturer	Samtec Inc.
Catalog	Rectangular Connectors
Description	CONN HEADER VERT 40POS 2.54MM
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Samtec Inc.
Packaging	Bulk
Connector Type	Header, Cuttable
Contact Type	Male Pin
Pitch - Mating	0.100" (2.54mm)
Number of Positions	40
Number of Rows	2
Row Spacing - Mating	0.100" (2.54mm)
Number of Positions Loaded	All
Style	Board to Board or Cable
Shrouding	Unshrouded
Mounting Style	Through Hole
Termination	Solder
Fastening Type	Push-Pull
Contact Length - Mating	0.380" (9.65mm)
Contact Length - Post	0.150" (3.81mm)
Overall Contact Length	0.630" (16.00mm)
Insulation Height	0.100" (2.54mm)
Contact Shape	Square
Contact Finish - Mating	Tin
Contact Finish - Post	Tin
Contact Material	Phosphor Bronze
Insulation Material	Polyester, Glass Filled
Temperature Range - Operating	-55°C ~ 105°C
Material Flammability Rating	UL94 V-0
Insulation Color	Black
Current Rating (Amps)	3A
Manufacturer Pack Quantity	1
MSL Level	Not Applicable
Popularity	Low
Supply and Demand Status	Limited
Win Source Part Number	812600-MTSW-120-22-T-D-380
Ultra Librarian 3D Model	Ultra Librarian MTSW-120-22-T-D-380 CAD Model

Alternative Products

Description

{"ProductId":750925,"FormattedDescription":"

The 812600-MTSW-120-22-T-D-380 is a 40-position, through-hole, male pin header connector from Samtec Inc.

Positions: 40
Mounting: Through Hole
Pitch: 0.100" (2.54mm)
Current Rating: 3A
Temperature Range: -55°C to 105°C
Style: Board to Board or Cable
Popularity: Low
