FTSH-110-01-L-DV-K-TR Real Image
Same model may have multiple batches, images only for reference.

FTSH-110-01-L-DV-K-TR

Part No FTSH-110-01-L-DV-K-TR
Manufacturer Samtec Inc.
Catalog Circular Connectors - Housings
Description CONN HEADER SMD 20POS 1.27MM / Connector Header Surface Mount 20 position 0.050" (1.27mm)
Datasheet
FTSH-110-01-L-DV-K-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Samtec Inc.
Series FTSH
Package Tape & Reel
Connector Type Header, Cuttable
Contact Type Male Pin
Pitch - Mating 0.050" (1.27mm)
Number of Positions 20
Number of Rows 2
Row Spacing - Mating 0.050" (1.27mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Unshrouded
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.120" (3.05mm)
Insulation Height 0.099" (2.51mm)
Contact Shape Square
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Contact Finish - Post Tin
Contact Material Phosphor Bronze
Insulation Material Liquid Crystal Polymer (LCP)
Features Keying Shroud
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Insulation Color Black
Current Rating (Amps) 3.4A per Contact
Base Product Number FTSH-110
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Other Names FTSH-110-01-L-DV-K-FR,SAM13960DKR,FTSH-110-01-L-DV-K-TR-ND,SAM13960CT,SAM13960TR
Standard Package 450
Win Source Part Number 1120581-FTSH-110-01-L-DV-K-TR
Ultra Librarian 3D Model Ultra Librarian FTSH-110-01-L-DV-K-TR CAD Model

Description

The Samtec Inc. FTSH series FTSH-110-01-L-DV-K-TR is a 20-position header connector with a keying shroud feature.

  • Positions: 20
  • Feature: Keying Shroud
  • Connector Type: Header, Cuttable
  • Contact Type: Male Pin
  • Positions Loaded: All
  • Rows: 2
  • Termination: Solder
  • Fastening Type: Push-Pull
  • Mounting: SMD (SMT)
  • Package: Tape and Reel
  • Contact Material: Phosphor Bronze
  • Contact Finish: Gold
  • Contact Finish Thickness: 10.0μin (0.25μm)
  • Pitch Mating: 0.050" (1.27mm)
  • Insulation: Liquid Crystal Polymer (LCP)
  • Flammability Rating: UL94 V-0
  • Applications: Board to Board, Cable
  • Current Rating: 3.4A per contact
  • Temperature Range: -55°C to 125°C
