The RLZTE-117.5A is a Zener diode produced by Rohm Semiconductor. Its primary function is to provide stable voltage regulation and protection against overvoltage conditions within electronic circuits. Zener diodes are frequently employed for creating stable reference voltages, clamping voltage spikes, and safeguarding sensitive components from potential damage.

Applications

• Voltage regulation in various power supplies
• Overvoltage protection in electronic devices
• Voltage clamping in circuit designs
• Reference voltage generation for precise control
• Transient voltage suppression to protect components

Features

• Stable Zener voltage of approximately 7.5V
• Low reverse leakage current for efficient operation
• High surge current capability for robust protection
• Surface Mount Device (SMD) package for easy assembly
• Excellent voltage clamping performance for reliable protection
• Pb-free plating to meet environmental standards

Benefits

• Provides stable voltage regulation, ensuring reliable circuit operation and performance.
• Protects sensitive electronic components from damage due to overvoltage and transient events.
• SMD package facilitates efficient assembly processes, reducing manufacturing costs and time.
• Offers excellent clamping performance, ensuring robust overvoltage protection for connected circuits.
• Environmentally friendly design and construction due to the use of Pb-free plating.

Additional Details

The RLZTE-117.5A Zener diode features a nominal Zener voltage (Vz) of roughly 7.5V. For specific voltage and tolerance information, always refer to the device's datasheet. It exhibits a low reverse leakage current (Ir), contributing to energy efficiency within the circuit. The diode is designed to withstand high surge currents, making it suitable for applications requiring transient voltage suppression. The use of an SMD package enables streamlined and automated assembly processes. Power dissipation for the device is typically in the range of 200-500mW, depending on the package type and thermal environment. Ensure you consult the product datasheet for complete electrical characteristics, including Zener voltage (Vz), reverse leakage current (Ir), and forward voltage (Vf) to ensure proper circuit design and optimal performance for your specific application. Operating temperature ranges are typically from -55°C to +150°C. The RLZTE-117.5A is well-suited for general-purpose voltage regulation and transient voltage suppression scenarios in electronic circuits.
