The LA-301ML is a linear Hall effect sensor IC manufactured by Rohm Semiconductor. It is designed to detect magnetic fields and provide a linear analog output voltage proportional to the magnetic field strength. This sensor is suitable for a wide range of applications requiring precise magnetic field measurement.

Applications

• Current sensing
• Position detection
• Speed sensing
• Brushless DC motor control
• Magnetic encoders

Features

• High sensitivity
• Linear output
• Wide operating voltage range
• Low noise
• Small package size

Benefits

• Enables precise measurement of magnetic fields.
• Provides a simple and predictable output signal.
• Accommodates various power supply configurations.
• Ensures accurate measurements in noisy environments.
• Allows for integration into compact systems.

Additional Details

The LA-301ML typically operates from a supply voltage of 2.7V to 5.5V. The output voltage is proportional to the applied magnetic field, with a typical sensitivity of around 1.8 mV/Gauss. The quiescent output voltage is typically half of the supply voltage. The sensor is available in a small SOT-23 package. It has a typical operating temperature range of -40°C to +85°C. This sensor is ideal for applications requiring accurate and reliable magnetic field sensing in a compact form factor. It offers good linearity and low offset drift over the operating temperature range.
