CD431690B Power Integrations
Same model may have multiple batches, images only for reference.

CD431690B

Part No CD431690B
Manufacturer Powerex Inc.
Catalog TVS - Thyristors
Description SCR MOD ISO DUAL 1600V 90A
Datasheet
CD431690B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Thyristors - SCRs - Modules
Mfr Powerex Inc.
Package Bulk
Product Status Active
Structure Series Connection - All SCRs
Number of SCRs, Diodes 2 SCRs
Voltage - Off State 1.6 kV
Current - On State (It (AV)) (Max) 95 A
Current - On State (It (RMS)) (Max) 150 A
Voltage - Gate Trigger (Vgt) (Max) 3 V
Current - Gate Trigger (Igt) (Max) 150 mA
Current - Non Rep. Surge 50, 60Hz (Itsm) 2000A, 2100A
Current - Hold (Ih) (Max) 250 mA
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting Type Chassis Mount
Package / Case POW-R-BLOK™ Module
Base Product Number CD431690
Standard Package 1 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.30.0080
Win Source Part Number 577119-CD431690B
Ultra Librarian 3D Model Ultra Librarian CD431690B CAD Model

Description

The 577119-CD431690B is a bulk-packaged thyristor module from Powerex Inc.

  • Category: Discrete Semiconductor Products - Thyristors - SCRs - Modules
  • Configuration: Series connection of two SCRs
  • Mounting Type: Chassis Mount
  • Maximum Off-State Voltage: 1.6 kV
  • Gate Trigger Voltage: 3 V
  • Maximum Hold Current: 250 mA
  • Gate Trigger Current: 150 mA
  • On-State Current (Average): 95 A
  • On-State Current (RMS): 150 A
  • Non-Repetitive Surge Current: 2000A/2100A for 50/60Hz
  • Package: POW-R-BLOK™
  • Operating Temperature: -40°C to 125°C (TJ)
