TOP224GN-TL Real Image TOP224GN-TL Real Image
Same model may have multiple batches, images only for reference.
TOP224GN-TL Real Image TOP224GN-TL Real Image
TOP224GN-TL Real Image TOP224GN-TL Real Image
Same model may have multiple batches, images only for reference.

TOP224GN-TL

Part No TOP224GN-TL
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLINE SWIT PWM OCP HV 8SMD
Datasheet
TOP224GN-TL Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Power Integrations
Packaging Reel - TR
Status Not For New Designs
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 700V
Topology Boost, Buck, Flyback, Forward
Duty Cycle 67%
Frequency - Switching 100kHz
Power (Watts) 30W
Fault Protection Current Limiting, Over Temperature
Control Operating Temperature -40°C to 150°C (TJ)
Case / Package 8-SMD
Mounting Surface Mount
Win Source Part Number 033353-TOP224GN-TL
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TOP224GN-TL CAD Model

Description

The Power Integrations TOP224GN-TL is a 30W electronic component with an 8-SMD case/package.

  • Component Use: This component is suitable for use in various electronic devices.
  • Voltage Breakdown: 700V
  • Frequency-Switching: 100kHz
  • Fault Protection: Current limiting and over-temperature protection
