TFS762HG Power Integrations
Same model may have multiple batches, images only for reference.

TFS762HG

Part No TFS762HG
Manufacturer Power Integrations
Catalog PMIC - AC DC Converters, Offline Switchers
Description IC OFFLIN CONV MULT TOP ESIP-16B
Datasheet
TFS762HG Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Power Management (PMIC) - AC DC Converters, Offline Switches
Mfr Power Integrations
Series HiperTFS®
Package Tube
Product Status Obsolete
Output Isolation Isolated
Internal Switch(s) Yes
Voltage - Breakdown 530V, 725V
Topology Flyback, Forward
Voltage - Start Up 12.1 V
Voltage - Supply (Vcc/Vdd) 11.1V ~ 13.4V
Duty Cycle 70%
Frequency - Switching 66kHz
Power (Watts) 360 W
Fault Protection Current Limiting, Over Temperature, Over Voltage, Short Circuit
Control Features EN
Temperature Range - Operating -40°C ~ 150°C (TJ)
Package / Case 16-SSIP, 12 Leads, Exposed Pad, Formed Leads
Supplier Device Package eSIP-16B
Mounting Type Through Hole
Base Product Number TFS762
Standard Package 30 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 684183-TFS762HG
Ultra Librarian 3D Model Ultra Librarian TFS762HG CAD Model

Description

The HiperTFS™ series by Power Integrations offers high-performance power management solutions for AC DC converters and offline switches.

  • Product: TFS762HG
  • Power Rating: 360W
  • Features: isolated output and internal switches
  • Breakdown Voltages: 530V and 725V
  • Topology: flyback and forward modes
  • Voltage Start-Up: 12.1V
  • Duty Cycle: 70%
  • Switching Frequency: 66kHz
  • Package: 16-SSIP with 12 leads and exposed pad
  • Operating Temperature Range: -40°C to 150°C
  • Status: obsolete
