The PS8336BQFN56GTR-A0, produced by Parade Technologies, is a DisplayPort to HDMI protocol converter designed to bridge the gap between DisplayPort source devices and HDMI displays. This IC facilitates seamless connectivity and high-resolution video output, catering to demanding multimedia applications with reliable signal transmission and compatibility.

Applications:

• Gaming Consoles: Connecting DisplayPort-enabled gaming consoles to HDMI televisions and monitors.
• Digital Signage: Deploying HDMI displays in digital signage applications using DisplayPort sources.
• Media Players: Providing HDMI output from media players with DisplayPort connectivity.
• Video Conferencing Systems: Enabling HDMI connectivity for video conferencing equipment using DisplayPort.
• Professional AV Equipment: Integrating DisplayPort sources with HDMI displays in professional audio-visual setups.

Features:

• DisplayPort 1.2a Input: Supports high-bandwidth DisplayPort input up to 5.4 Gbps per lane.
• HDMI 1.4b Output: Provides HDMI output with support for resolutions up to 4K Ultra HD (3840x2160) at 30Hz.
• HDCP 1.4 Content Protection: Ensures secure transmission of protected content with High-bandwidth Digital Content Protection.
• Audio Support: Handles various audio formats, including Dolby Digital, DTS, and LPCM.
• Low Power Consumption: Efficient power usage suitable for a wide range of applications.
• QFN56 Package: Compact Quad Flat No-Lead package ideal for space-constrained designs.

Benefits:

• Universal Connectivity: Ensures compatibility between DisplayPort source and HDMI displays.
• High-Definition Output: Supports up to 4K Ultra HD resolution for sharp and detailed video.
• Stable Signal Transmission: Guarantees reliable and error-free transmission of video and audio signals.
• Immersive Multimedia: Delivers high-quality audio and video for enhanced multimedia experiences.
• Energy Efficient: Minimizes power consumption, making it suitable for energy-sensitive applications.

Additional Details:

The PS8336BQFN56GTR-A0 is designed to operate on a 3.3V power supply. Its integrated HDCP engine ensures secure transmission of protected content, making it a reliable solution for converting DisplayPort signals to HDMI. Its advanced features and compact package make it suitable for various applications requiring seamless connectivity and high-performance video output.
