The BAV99ST/R is a high-speed switching diode array manufactured by Panjit. It contains two series-connected diodes in a single SOT-363 package, making it suitable for applications requiring fast switching speeds and efficient signal routing.

Applications

• High-speed switching circuits
• General-purpose rectification
• Protection circuits
• Small signal switching
• Mobile devices

Features

• Two series-connected diodes
• High switching speed
• Low forward voltage drop
• Small SOT-363 package
• Lead-free termination

Benefits

• Reduced Board Space: The dual-diode configuration in a single package saves valuable board space.
• Fast Switching Speed: Enables efficient signal routing and high-speed operation in switching circuits.
• Low Forward Voltage Drop: Minimizes power dissipation and improves circuit efficiency.
• Easy to Integrate: The SOT-363 package simplifies surface mount assembly.
• Reliable Performance: Provides consistent and reliable performance in demanding applications.

Additional Details

The BAV99ST/R is commonly used in mobile devices and other applications where size and performance are critical. The diodes are connected in series, providing a higher reverse voltage capability. Refer to the datasheet for detailed electrical characteristics, including forward voltage, reverse recovery time, and junction capacitance. The /R suffix likely indicates a specific tape and reel packaging option for automated assembly.
