Same model may have multiple batches, images only for reference.
UNHS20300L Real Image
Same model may have multiple batches, images only for reference.

UNHS20300L

Part No UNHS20300L
Manufacturer Panasonic
Catalog Fuses
Description FUSE BOARD MOUNT 1.2A 50VAC/VDC
Datasheet
UNHS20300L Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Panasonic Electronic Components
Packaging Cut Reel
Status Obsolete(EOL)
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating 1.2A
Voltage Rating - AC 50V
Voltage Rating - DC 50V
Response Time Fast
Mounting SMD (SMT)
Temperature Range - Operating -55°C to 125°C
Nominal Cold Resistance 0.045 Ohm
Win Source Part Number 053332-UNHS20300L
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian UNHS20300L CAD Model

Description

The UNHS20300L is a cut reel packaged board mount (cartridge style excluded) fuse type.

  • Current Rating: 1.2A
  • Voltage Rating (AC and DC): 50V
  • Response Time: fast
  • Approvals: no approvals
  • Mounting Type: SMD (SMT)
  • Operating Temperature Range: -55°C to 125°C
  • Nominal Cold Resistance: 0.045 Ohm
  • Nominal Melting - I2t: not specified
  • Status: obsolete (EOL) product of Panasonic Electronic Components
