The EXB2HV470JV is a thick film resistor network array manufactured by Panasonic. This component integrates multiple resistors into a single package, offering space savings and simplifying circuit design. It features a 47-ohm resistance value for each resistor element and is designed for general-purpose applications in electronic circuits.

Applications

• Pull-up/pull-down resistors
• Current limiting resistors
• Voltage dividers
• Logic circuits
• Digital circuits

Features

• Four isolated resistor elements in a single package
• Resistance value: 47 ohms
• Tolerance: ±5%
• Power rating: 0.063W per resistor
• Thick film construction
• Surface mount technology (SMT)

Benefits

• Space savings on printed circuit boards (PCBs)
• Reduced component count, simplifying assembly
• Improved circuit reliability
• Easy integration into automated manufacturing processes
• Consistent performance across all resistor elements
• Cost-effective solution for multiple resistor applications

Additional Details

The EXB2HV470JV resistor network array consists of four individual 47-ohm resistors, each with a tolerance of ±5%. The thick film construction provides stable and reliable performance over a wide range of operating conditions. The surface mount package allows for easy integration into automated assembly processes. The component is suitable for a variety of applications where multiple resistors are required. The EXB2HV470JV offers a compact and cost-effective solution for resistor applications in electronic circuits.

The resistor network is commonly used in digital circuits for pull-up and pull-down applications, ensuring proper logic levels. It can also be used as current limiting resistors to protect sensitive components from overcurrent conditions. The EXB2HV470JV is a versatile component that simplifies circuit design and reduces the overall cost of electronic products. The device helps to minimize board space, and reduce manufacturing costs.
