The ECHU1C152JX5 is a film capacitor manufactured by Panasonic, part of the ECQU series known for general purpose applications. These capacitors are built for reliable operation and stable performance across a wide range of electronic circuits.

Applications

• Power Supplies: For filtering and smoothing DC voltage in power supplies.
• Consumer Electronics: Used in televisions, audio equipment, and other consumer devices for signal coupling, decoupling, and filtering.
• Industrial Equipment: Found in motor drives, inverters, and other industrial applications.
• Lighting Ballasts: Used in electronic ballasts for fluorescent and LED lighting.
• Noise Suppression: Reduces electromagnetic interference (EMI) in electronic circuits.
• Signal Coupling and Decoupling: Isolates signals and reduces noise in analog and digital circuits.
• Snubber Circuits: Protects switching devices from voltage transients.
• Filtering Circuits: Filters unwanted frequencies in various electronic circuits.

Features

• Metallized Film Construction: Offers self-healing properties and improved reliability.
• Polyester Film Dielectric: Provides stable capacitance and low dissipation factor.
• Compact Size: Allows for high-density mounting on circuit boards.
• High Moisture Resistance: Suitable for use in humid environments.
• Flame Retardant Coating: Enhances safety and reduces fire risk.
• RoHS Compliant: Meets environmental regulations for hazardous substances.
• Excellent Pulse Handling Capability: Suitable for applications with high pulse currents.
• Long Life: Designed for extended operational life.

Benefits

• Reliable Performance: Ensures stable and consistent operation in various circuits.
• Compact Design: Allows for efficient use of space on circuit boards.
• High Safety: Flame retardant coating provides added protection.
• Environmentally Friendly: RoHS compliance demonstrates environmental responsibility.
• Versatile Use: Suitable for a wide range of general-purpose applications.
• Noise Reduction: Effectively suppresses noise and improves signal integrity.

Additional Details

The ECHU1C152JX5 has a capacitance of 1500 pF (picofarads) or 1.5 nF (nanofarads). The '1C' in the part number specifies the voltage rating, and the 'JX5' details the lead style and packaging. It's crucial to refer to the official Panasonic datasheet for the specific voltage rating (typically 50V or 100V), capacitance tolerance, operating temperature range, and physical dimensions to ensure proper application. This capacitor is designed for automated assembly in high-volume manufacturing.
