AQY282S Real Image AQY282S Real Image1 AQY282S Real Image2
Same model may have multiple batches, images only for reference.
AQY282S Real Image AQY282S Real Image1 AQY282S Real Image2
AQY282S Real Image AQY282S Real Image1 AQY282S Real Image2
Same model may have multiple batches, images only for reference.

AQY282S

Part No AQY282S
Manufacturer Panasonic
Catalog Solid State Relays
Description SSR RELAY SPST-NO 500MA 0-60V / Solid State SPST-NO (1 Form A) 4-SOP (0.173", 4.40mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Panasonic
Series PhotoMOS™ AQY
Package Tube
Product Status Active
Mounting Type Surface Mount
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.14VDC
Voltage - Load 0 V ~ 60 V
Load Current 500 mA
On-State Resistance (Max) 2.5 Ohms
Termination Style Gull Wing
Package / Case 4-SOP (0.173", 4.40mm)
Supplier Device Package 4-SOP
Base Product Number AQY282
Standard Package 100 pcs
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 564474-AQY282S
Ultra Librarian 3D Model Ultra Librarian AQY282S CAD Model

Description

The PhotoMOS™ AQY series from Panasonic offers solid-state relays with high performance and reliability. The AQY282S is a surface mount device with a gull wing termination style.

  • Voltage Input: 1.14VDC
  • Output Types: AC and DC
  • Circuit Configuration: SPST-NO (1 Form A)
  • Maximum On-State Resistance: 2.5 Ohms
  • Load Current: 500 mA
  • Voltage Load Range: 0 V to 60 V
  • Package: 4-SOP
  • Standard Package: 100 pcs
  • Product Status: active
