ON Semiconductor NL27WZ14DFT2G Dual Inverter

The NL27WZ14DFT2G from ON Semiconductor is a high-performance dual inverter integrated circuit designed for a wide range of applications requiring logic level conversion and signal inversion. This versatile component is a part of ON Semiconductor's range of advanced high-speed CMOS devices, offering the perfect balance between speed and power consumption.

Key Features

• Logic Type: The NL27WZ14DFT2G is a dual inverter, which means it contains two independent inverters in a single package, allowing for efficient use of space and reduction of component count in circuit designs.
• High-Speed Operation: It is capable of high-speed operation, with a typical propagation delay time of only 2.6 ns, facilitating swift signal processing in critical applications.
• Low Power Consumption: Despite its high-speed capabilities, the NL27WZ14DFT2G maintains low power consumption, making it suitable for portable and battery-powered devices.
• Operating Voltage Range: The device supports a broad operating voltage range from 1.65V to 5.5V, providing design flexibility for interfacing with both low-voltage and standard logic level circuits.
• High Output Drive: With a high output drive capability at 24 mA, this inverter can drive multiple loads or interface with other logic families seamlessly.
• Over-Voltage Tolerant Inputs: The inputs are over-voltage tolerant up to 5.5V, which helps in protecting the device against unexpected voltage spikes.

Applications

The NL27WZ14DFT2G is ideal for various applications, including:

• Signal buffering and inversion
• Logic level translation
• Line driving
• Wave shaping and pulse generation
• Clock generation circuits

Package and Quality

Encased in a compact SC-88 (SOT-363) surface-mount package, the NL27WZ14DFT2G is designed for space-saving PCB layouts. ON Semiconductor's commitment to quality ensures that each device meets rigorous industry standards for performance and reliability, making the NL27WZ14DFT2G a trusted choice for engineers and designers looking for a dependable dual inverter solution.
