The ON Semiconductor NCP1096PAG is a cutting-edge interface controller designed for high-performance applications that require efficient power over Ethernet (PoE). This device is compliant with the IEEE 802.3bt standard, which ensures its compatibility with the latest PoE systems capable of delivering up to 90 Watts of power over a single Ethernet cable. The NCP1096PAG is an ideal solution for powering devices such as wireless access points, security cameras, and Internet of Things (IoT) devices in a wide range of industrial and commercial settings.

Key Features

• IEEE 802.3bt Compliant: Supports the latest PoE standard for up to 90W power delivery.
• Integrated Power MOSFET: Features a built-in power MOSFET for streamlined power management.
• Advanced Thermal Protection: Equipped with thermal shutdown mechanisms to prevent overheating and ensure device longevity.
• Signature Resistor Detection: Includes a programmable signature resistor for flexible device classification.
• Robust Package: Housed in a rugged 16-pin QFN package for enhanced durability and reduced space requirements.

Applications

The NCP1096PAG is versatile and can be used in various applications that require reliable and efficient power distribution through Ethernet cables. Its robust design and compliance with the latest PoE standard make it an excellent choice for:

• Wireless Access Points
• IP Surveillance Cameras
• VoIP Phones
• Point of Sale (POS) Systems
• Network Routers and Switches
• Smart Lighting Systems

Benefits

With the NCP1096PAG, users can expect a high level of efficiency and reliability. The device's integrated features reduce the need for external components, which can simplify design and reduce costs. Additionally, its advanced protection features ensure that both the controller and the powered device are safeguarded against potential electrical hazards, contributing to a secure and stable network environment.
