Product Overview: MC74VHC1G04DTT1G from ON Semiconductor

The MC74VHC1G04DTT1G is a high-speed CMOS inverter integrated circuit (IC) fabricated by ON Semiconductor, a leader in energy-efficient innovations. This device is designed to deliver the ultimate in performance for modern electronic designs, ensuring both high-speed operation and minimal power consumption.

Key Features

• Logic Type: CMOS Inverter
• Supply Voltage Range: 2V to 5.5V, accommodating a variety of logic level requirements and ensuring compatibility with both low and high voltage systems.
• High Speed: Propagation delay times as low as 2.6ns at VCC = 5V, making it suitable for high-speed applications.
• Low Power Dissipation: With a static power consumption of only 1µA maximum at VCC = 5.5V, the device is ideal for power-sensitive designs.
• High Noise Immunity: The VHC series is known for its excellent noise immunity, characteristic of CMOS technology.
• Output Drive Capability: Capable of driving 8mA at 5V, allowing for direct drive of small loads.
• Package: Supplied in a small, surface-mount package (DTT1G), optimizing board space and enabling use in compact electronic assemblies.

Applications

The MC74VHC1G04DTT1G is versatile and can be used in a wide range of applications, including:

• Logic level conversion
• Wave shaping
• Signal inversion
• High-speed computing
• Portable and battery-powered electronics

Quality and Reliability

ON Semiconductor is committed to providing high-quality products. The MC74VHC1G04DTT1G is no exception, with rigorous testing and quality assurance measures in place to ensure reliable performance in demanding environments.

For designers and engineers looking for a dependable and efficient inverter solution, the MC74VHC1G04DTT1G from ON Semiconductor stands out as a component that meets stringent performance criteria while simplifying design complexities.
