Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 35V
Current - Average Rectified (Io) 8A
Voltage - Forward (Vf) (Max) @ If 510mV @ 8A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 1.4mA @ 35V
Mounting SMD (SMT)
Case / Package DPAK-3
Operating Temperature - Junction -65°C to 150°C
Win Source Part Number 022431-MBRD835LT4G
Family Name MBRD835L
Introduction Date May 07, 1996
ECCN EAR99
Country of Origin China, Malaysia, Vietnam
Halogen Free Compliant
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Application Field Used in Power Management, Automotive, Industrial
Ultra Librarian 3D Model Ultra Librarian MBRD835LT4G CAD Model

Description

The MBRD835LT4G from ON Semiconductor is a state-of-the-art Schottky Barrier Rectifier designed for high-efficiency power management applications. This rectifier is a surface mount device encapsulated in a DPAK (TO-252) package, which is well-suited for compact designs where space is at a premium.

With its robust construction, the MBRD835LT4G is capable of withstanding a peak repetitive reverse voltage of 35V and a continuous forward current of 8A. Its low forward voltage drop and fast switching capability make it an excellent choice for switch-mode power supplies, converters, and freewheeling diodes in a variety of electronic devices.

Key features of the MBRD835LT4G include:

  • High Surge Capacity: The device can handle high surge currents, which is critical for applications that may experience sudden overloads.
  • Low Power Loss: With its low forward voltage drop, this rectifier ensures minimal power loss during operation, which enhances the overall efficiency of the system.
  • Thermal Stability: The MBRD835LT4G can operate over a wide temperature range, maintaining its performance even under thermal stress.
  • Guard Ring Die Construction: The inclusion of a guard ring helps to improve the device's transient performance and reliability.

Applications for the MBRD835LT4G are diverse, ranging from power supply rectification to battery charging circuits. Its compact footprint and high-efficiency characteristics make it an ideal choice for portable devices, telecommunications equipment, and automotive applications where power density and efficiency are critical.

ON Semiconductor's commitment to quality ensures that the MBRD835LT4G meets the stringent requirements of the modern electronics industry. With its combination of performance, reliability, and compact size, this Schottky Barrier Rectifier is an essential component for designers looking to optimize their power management solutions.
