The OB2269AP is a highly integrated current mode PWM control IC optimized for off-line flyback converter applications. It provides a cost-effective solution for power supplies requiring high performance and comprehensive protection features.

Applications:

• Adapters for laptops and other portable devices.
• Power supplies for set-top boxes.
• Open-frame power supplies for industrial applications.
• LED lighting drivers.
• Auxiliary power supplies.

Features:

• Current Mode PWM Control: Offers excellent line regulation, load regulation and transient response.
• Low Startup Current: Reduces power loss during startup, improving efficiency.
• Internal Slope Compensation: Prevents sub-harmonic oscillation at high duty cycles.
• Cycle-by-Cycle Current Limiting: Provides protection against overload and short circuit conditions.
• Over Voltage Protection (OVP): Protects the output from overvoltage damage.
• Over Temperature Protection (OTP): Prevents damage caused by excessive temperature.
• Short Circuit Protection (SCP): Protects the power supply from short circuit faults.
• Open Loop Protection: Disables the PWM output to prevent damage in case of an open loop.
• Frequency Jittering for Improved EMI: Reduces electromagnetic interference.
• Available in DIP-8 Package: Cost-effective and easy to use.

Benefits:

• High Efficiency: Minimizes power loss and reduces heat generation.
• Improved Reliability: Comprehensive protection features ensure robust performance.
• Reduced BOM Cost: High integration minimizes external components.
• Simplified Design: Current mode control simplifies the design process.
• Enhanced EMI Performance: Frequency jittering reduces electromagnetic emissions.

Additional Details:

The OB2269AP utilizes a current-mode PWM control scheme to provide excellent line regulation, load regulation, and transient response. The integrated features and protection functions significantly reduce the external component count, simplifying the design and reducing the overall cost. Its low startup current and optimized operating frequency contribute to improved efficiency. The built-in slope compensation circuit prevents sub-harmonic oscillation, ensuring stable operation under various operating conditions. The device is available in a standard DIP-8 package for ease of manufacturing.

The OB2269AP is a reliable and efficient solution for a wide range of power supply applications. Its robust protection features and low cost make it an ideal choice for designers looking for a high-performance and cost-effective solution.
