The MSM5117400F-60TS-K is a 4M-bit dynamic RAM (DRAM) manufactured by OKI/Metcal. It's organized as 4,194,304 words × 1 bit. This DRAM offers high-speed access and is suitable for various applications where temporary data storage is needed.

Applications:

• Memory modules in computers and embedded systems
• Video memory in graphics cards
• Cache memory in processors
• Digital signal processing (DSP) systems
• Networking equipment

Features:

• Access Time: 60 ns
• Organization: 4,194,304 words × 1 bit
• Power Supply Voltage: 5V
• Refresh: Self Refresh
• Package: SOJ (Small Outline J-lead)
• Low Power Consumption

Benefits:

• High Speed: The 60ns access time enables rapid data retrieval and storage, crucial for real-time applications.
• Large Capacity: The 4M-bit density allows storage of significant amounts of data, reducing the need for frequent memory swapping.
• Low Power Consumption: Minimizes energy usage, making it suitable for battery-powered devices and energy-efficient systems.
• Easy Integration: The SOJ package simplifies board assembly and reduces manufacturing costs.
• Reliable Performance: Designed for stable and consistent operation, ensuring data integrity and system stability.

Technical Specifications:

The MSM5117400F-60TS-K operates with a 5V power supply and has a typical operating current of around 50mA. It uses a multiplexed address input, reducing the number of address pins required. The device utilizes a refresh mechanism to retain data, typically involving a self-refresh mode for low-power standby operation. It is packaged in a standard SOJ package suitable for surface mount technology. The operating temperature range is typically 0°C to 70°C.

The DRAM is fabricated using advanced CMOS technology, ensuring low power consumption and high reliability. It's commonly used in older computer systems, embedded controllers, and other applications that require relatively high speed and moderate memory capacity. This part offers a good balance of performance, power consumption, and cost, making it a popular choice for many legacy applications.

In summary, the MSM5117400F-60TS-K is a reliable and efficient 4M-bit DRAM ideal for applications requiring fast access and moderate memory capacity. Its low power consumption and ease of integration make it a versatile component for various electronic systems.
