Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Type Steering (Rail to Rail)
Unidirectional Channels 4
STAND-OFF Voltage (Vwm) 5.5V (Max)
Minimum Breakdown Voltage 6V
Max Clamping Voltage 4.6V (Typ)
Peak Pulse Current(Ippm) 5.2A (8/20μs)
Power Line Protection Yes
Applications HDMI
Temperature Range - Operating -40°C to 85°C (TA)
Mounting SMD (SMT)
Case / Package 10-DFN2510 (2.5x1)
Win Source Part Number 112526-PUSB3F96
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian PUSB3F96 CAD Model

Description

The NXP PUSB3F96 is a cutting-edge USB 3.1 Gen 1 re-driver designed to enhance signal quality and integrity in applications where signals are prone to degradation due to long PCB traces or cables. This advanced re-driver is an essential component for maintaining high-speed communication and ensuring reliable connectivity in various consumer, industrial, and automotive applications.

Key Features

  • High-Speed Performance: Supports USB 3.1 Gen 1 data rates up to 5 Gbps, ensuring fast data transfer for applications such as external storage, video streaming, and more.
  • Signal Integrity: Employs advanced equalization techniques to compensate for signal loss and reduce inter-symbol interference, thus enhancing signal quality over extended distances.
  • Flexibility: Features programmable settings for equalization, output swing, and flat gain to optimize performance for specific applications and cable types.
  • Energy Efficiency: Includes a low-power mode that significantly reduces power consumption when in standby or when the link is inactive, making it suitable for energy-conscious designs.
  • Easy Integration: Offered in a compact package, the PUSB3F96 is designed for easy implementation into existing designs without the need for significant PCB layout changes.

Applications

The versatility of the NXP PUSB3F96 makes it suitable for a wide range of applications, including:

  • USB 3.1 Gen 1 Hubs and Docking Stations
  • High-Speed Data Transfer Cables
  • Desktop and Laptop Computers
  • Consumer Electronics
  • Automotive Infotainment Systems

Technical Specifications

Parameter Specification Data Rate Up to 5 Gbps Supply Voltage 3.3V ± 10% Operating Temperature -40°C to 85°C Package Compact QFN

With its robust feature set and performance capabilities, the NXP PUSB3F96 is an ideal solution for designers looking to overcome the challenges of high-speed USB signal transmission in their products.
