The PTN3360ABS is a high-performance, DisplayPort to VGA adapter IC designed and manufactured by NXP Semiconductors. This compact and efficient integrated circuit offers a seamless solution for connecting DisplayPort-enabled devices to VGA displays, making it an ideal choice for a wide range of applications such as personal computers, laptops, and other multimedia devices.

Key Features

• DisplayPort to VGA Conversion: The PTN3360ABS bridges the gap between modern DisplayPort outputs and legacy VGA inputs, supporting video resolutions up to 1920x1200 for full HD video quality.
• EDID Support: It includes an integrated Extended Display Identification Data (EDID) buffer, ensuring that the connected DisplayPort source can recognize and optimize the display settings for the connected VGA monitor.
• Plug and Play: Designed for ease of use, the PTN3360ABS does not require any software drivers, offering a plug-and-play experience for users.
• Low Power Consumption: The device operates with low power consumption, making it suitable for battery-powered devices where power efficiency is critical.
• Compact Package: Available in a small HVQFN32 package, the PTN3360ABS is designed for space-constrained applications.

Applications

The PTN3360ABS is versatile and can be used in various devices and setups that require the conversion of DisplayPort signals to VGA. It is particularly useful in scenarios where there is a need to connect newer generation laptops or computers to older monitors or projectors that only support VGA input.

Technical Specifications

• Package: HVQFN32
• Resolution Support: Up to 1920x1200 (WUXGA)
• Power Supply: 3.3V
• Operating Temperature: 0°C to 70°C

With its robust design and comprehensive feature set, the PTN3360ABS from NXP stands out as a reliable and efficient solution for video signal conversion. It is a testament to NXP's commitment to providing cutting-edge technology that addresses the evolving needs of video connectivity.
