The NXP PCF8566T/S480/1,11 is a versatile LCD driver, designed to drive dot matrix graphic displays of up to 24 segments and 4 commons. This makes it an ideal solution for a wide range of applications that require alphanumeric displays, such as consumer electronics, automotive dashboards, industrial controls, and handheld meters.

Key Features

• Display Flexibility: Capable of driving displays with up to 96 segments, providing flexibility for a variety of display requirements.
• Low Power Consumption: Engineered for battery-powered devices, the PCF8566T/S480/1,11 features a low power consumption mode that significantly extends battery life.
• Interface Options: Supports both I²C-bus and SPI-bus interfaces, allowing for easy integration with most microcontrollers.
• Multiplexing Capability: Offers a 1:4 multiplex rate, which is key for achieving a high-quality display with a limited number of I/O lines.
• On-Chip Generation of LCD Supply Voltage: No need for external components to generate the LCD supply voltage, simplifying the design and reducing the bill of materials.

Product Applications

The PCF8566T/S480/1,11 is designed to meet the needs of a diverse range of applications, which include:

• Automotive dashboard displays
• Portable instruments
• Medical equipment
• Home appliances
• Point of sale terminals

Technical Specifications

With its robust feature set and NXP's reputation for quality and reliability, the PCF8566T/S480/1,11 LCD driver is an excellent choice for developers looking to create sophisticated display solutions for their products.
