NXP MC9S08FL8CBM Microcontroller

The NXP MC9S08FL8CBM is a versatile and powerful microcontroller that is part of the S08 family, designed to cater to a wide range of applications requiring efficient and low-power operation. This microcontroller is built on a Silicon-On-Insulator (SOI) process that enhances its performance and robustness, particularly in harsh electrical environments.

Key Features

• Core: The MC9S08FL8CBM is equipped with an S08 core, which operates at a bus frequency of up to 20 MHz, providing a balance between processing power and energy efficiency.
• Memory: It comes with 8 KB of on-chip flash memory and 512 Bytes of RAM, allowing for efficient program and data storage.
• Timers: Multiple timing systems including an 8-channel, 16-bit timer/pulse-width modulator (TPM) ensure precise timing operations and PWM control.
• Communication Interfaces: The microcontroller features a rich set of communication interfaces such as I²C, SPI, and SCI, enabling easy connectivity with peripheral devices and other microcontrollers.
• Analog to Digital Converter (ADC): An integrated 12-bit ADC allows for accurate analog signal measurement and conversion, making it ideal for sensor interfacing.
• Supply Voltage: The device operates at a voltage range of 1.8V to 3.6V, supporting battery-powered and portable applications.
• Temperature Range: It is designed to work within an industrial temperature range of -40°C to +85°C, ensuring reliability in extreme conditions.
• Packaging: The MC9S08FL8CBM is available in a compact 16-pin QFN package, which is suitable for space-constrained applications.

Applications

The NXP MC9S08FL8CBM is ideal for a broad range of applications, including but not limited to consumer electronics, industrial control systems, automotive modules, and smart sensors. Its low-power consumption and rich feature set make it particularly well-suited for portable and battery-operated devices.

Design Support

NXP provides comprehensive development support for the MC9S08FL8CBM with software libraries, development tools, and reference designs to help accelerate the product development process. This ensures that engineers can leverage the full capabilities of the microcontroller to create innovative and efficient designs.
